Ultrasonic Sensor Library for Proteus

Ultrasonic Sensor Library for Proteus comes as a RAR archive of 3 files (3 KB, 16.3 KB unpacked) holding Proteus library files and compiled HEX firmware.

LIBProteus library
IDXProteus library index
HEXHEX firmware

Description

This is the download page of Ultrasonic Sensor Library for Proteus, the file package of the tutorial Ultrasonic Sensor Library for Proteus, published on The Engineering Projects in February 2015. Here you get the RAR file (3 KB) with the Proteus library files (LIB and IDX) and the compiled HEX firmware, the list of files it contains, the README when there is one, and the installation steps in order.

What this library is

Ultrasonic Sensor Library for Proteus adds Ultrasonic Sensor to Proteus as a schematic component: once installed, the part appears in the Pick Devices list under its own name, with its real pin layout, and can be placed and wired like any built-in device. It is a symbol-and-footprint library: it draws and routes the part; to see it work in simulation, pair it with the HEX file or the controller model as the tutorial shows.

What is inside the RAR file

UltrasonicTEP.LIB – Proteus library, 15.1 KB
UltrasonicTEP.IDX – Library index, 129 B
UltraSonicTEP.HEX – Compiled HEX file, 1 KB

The archive unpacks to 16.3 KB; there is no README inside, so the steps below stand in for it.

How to download

Use the download panel at the top of this page: after the counter (30 seconds for guests, 10 for members) the black button unlocks and Ultrasonic Sensor Library for Proteus.rar comes straight from our content network. If the browser opens it instead of saving, use Save as; extract the whole archive before using anything inside it.

How to install

Step 1: Extract Ultrasonic Sensor Library for Proteus.rar with Windows (Extract All), 7-Zip or WinRAR.
Step 2: Close Proteus and copy UltrasonicTEP.LIB and UltrasonicTEP.IDX into its LIBRARY folder (Proteus 8: C:\Program Files (x86)\Labcenter Electronics\Proteus 8 Professional\LIBRARY).
Step 3: Start Proteus, press P and search for "UltrasonicTEP"; place and wire it as in the tutorial.
Step 4: In Proteus set the controller's Program File to UltraSonicTEP.HEX; on hardware, flash the same file.

Simulation and results

To see Ultrasonic Sensor working, build the tutorial's schematic in Proteus, load the HEX into the controller and press Play; compare with the tutorial's screenshots. If nothing runs, make sure every library file was copied before Proteus started and that Program File points at the HEX on your disk; the FAQs tab covers the usual causes.

Read the detailed guide

This page is for the files. The tutorial above explains the circuit and the code step by step and shows the working results; read it before you build. Questions about the download or the installation go in the comments below; more Proteus downloads are listed further down this page.

The package is free for personal, educational and research projects; credit The Engineering Projects and link to this page when you share it rather than re-uploading the file.

Read Ultrasonic Sensor Library for Proteus

File Structure

Ultrasonic Sensor Library for Proteus.rar3 files · 0 folders · 16.3 KB unpacked

HEX UltraSonicTEP.HEXCompiled HEX file 1 KB

IDX UltrasonicTEP.IDXLibrary index 129 B

LIB UltrasonicTEP.LIBProteus library 15.1 KB

Gallery6 images from the tutorialOpen the tutorial

The circuit, the board and the results as they appear in Ultrasonic Sensor Library for Proteus. Open an image for its full size.

HC-SR04-style ultrasonic model placed in Proteus, HC-SR04 model, Arduino Uno interface, distance simulation — HC-SR04-style ultrasonic model placed in Proteus.

Selecting UltrasonicTEP HEX in sensor properties, HC-SR04 model, Arduino Uno interface, distance simulation — Selecting UltrasonicTEP HEX in sensor properties.

Components selected for the ultrasonic simulation, HC-SR04 model, Arduino Uno interface, distance simulation — Components selected for the ultrasonic simulation.

Arduino Uno and ultrasonic sensor simulation wiring, HC-SR04 model, Arduino Uno interface, distance simulation — Arduino Uno and ultrasonic sensor simulation wiring.

Ultrasonic distance readings in the Proteus Virtual Terminal, HC-SR04 model, Arduino Uno interface, distance simulation — Ultrasonic distance readings in the Proteus Virtual Terminal.

README

README no readme

This package has no README file. The Install tab explains where each file goes, and the tutorial Ultrasonic Sensor Library for Proteus walks through the whole project.

Development1 release

11 Feb 2015
Ultrasonic Sensor Library for Proteusthis page

The only release of this package so far. When a newer version is published, it appears above with its own download page.

Installation5 steps

From the download to a working project, in order. The steps follow what the package contains.

You will need

Proteus Design SuiteProteus 8 or newer (Labcenter), on Windows
WinRAR or 7-ZipWindows cannot open RAR archives on its own

Steps

1
Extract the archive
Right-click Ultrasonic Sensor Library for Proteus.rar and choose Extract All (or open it with 7-Zip or WinRAR) into a folder you can find again.
2
Copy the library files into Proteus
Move UltrasonicTEP.LIB and UltrasonicTEP.IDX into the LIBRARY folder of your Proteus installation: C:\Program Files (x86)\Labcenter Electronics\Proteus 8 Professional\LIBRARY for Proteus 8, or the matching Proteus 7 folder. Older versions keep it under ProgramData\Labcenter Electronics. If Proteus is open, close it first.
3
Restart Proteus and place the component
Start Proteus, open a schematic, press P (Pick Devices) and search for the component by the name used in the tutorial. It appears with its pins ready to wire.
4
Load the HEX file
In Proteus double-click the microcontroller, set Program File to UltraSonicTEP.HEX and run the simulation. For real hardware, flash the same file with your programmer.
5
Follow the tutorial
Ultrasonic Sensor Library for Proteus explains every connection and setting in order; keep it open beside the files while you build.

How to add a library in Proteus 8

FAQs11 questionsContact TEP

How do I download Ultrasonic Sensor Library for Proteus?

Wait for the 30-second guest countdown on this page, then press the download button; the file comes straight from our storage. Members who are logged in skip the wait. If the browser opens the file instead of saving it, use its Save as option.

What is inside the archive?

Ultrasonic Sensor Library for Proteus comes as a RAR archive of 3 files (3 KB, 16.3 KB unpacked) holding Proteus library files and compiled HEX firmware. Open the File Structure tab for the full list of 3 files.

What should I do if the download does not start?

Check the browser's download list first; an ad blocker or a company firewall can also hold it back, so try another browser or network. If the file arrives incomplete, download it again. For an installation problem, read the Install tab or tell us in the comments with your software version and the exact error message.

Is this file free?

Yes. Every file in the TEP Download Center is free for learning, personal and student projects. If you share it, link back to this page or the tutorial so others find the latest version.

How do I check that the file arrived complete?

Compare its SHA-256 with the one on this page, d0df51e20d0df2bc30ad7457760876d88a4477215fe17a05a1d8ce8dbed9cfa1. In PowerShell run Get-FileHash "Ultrasonic Sensor Library for Proteus.rar"; on macOS or Linux run shasum -a 256 "Ultrasonic Sensor Library for Proteus.rar". The same value means the file is exactly the one in our storage; a different one means the download broke off, so download it again.

Do I need WinRAR to open the RAR file?

RAR archives need WinRAR, 7-Zip or another RAR-capable tool; Windows cannot open them on its own. Extract the whole archive before using the files.

Where do I put the LIB and IDX files?

Both files go into the LIBRARY folder of your Proteus installation (Proteus 8: C:\Program Files (x86)\Labcenter Electronics\Proteus 8 Professional\LIBRARY; Proteus 7 has the same folder under its own name). Restart Proteus afterwards and search for the component with P.

Which Proteus version does the library need?

The tutorial names the Proteus version the library was made and tested with. Most TEP libraries work in Proteus 7 and Proteus 8; if the component does not appear after a restart, check that both the LIB and the IDX file were copied and that Proteus was fully closed while copying.

Why does the component show but not simulate?

A library without a model file (DLL) gives you the symbol and the pins for drawing and PCB design; the simulation needs the matching model or a HEX file on the controller, exactly as the tutorial describes.

How do I get the HEX file into the simulation?

Compile the sketch in the Arduino IDE (Sketch → Export Compiled Binary gives you the HEX next to the sketch), then in Proteus double-click the board, set Program File to that HEX and run.

Are there other files for this tutorial?

Yes, this tutorial has 2 downloads; the others are listed under the panel. Each has its own page and countdown.
