Hello friends, I hope you all are doing great. Today, I am going to share the new 3.5" TFT LCD Shield Library for Proteus V1.0 . When the 2.4" screen gets too small for your menus, meters and buttons, the next step on an Arduino UNO is the red 3.5 inch TFT LCD shield : 480 x 320 pixels, twice the pixels of the 2.4" shield, the same 65,536 colours and the same resistive touch screen , and it still plugs straight on the UNO. With this 3.5" TFT LCD Shield Library for Proteus , you can design a full-size touch interface, test it in the simulation and see exactly what the real shield would show, pressing the glass with your mouse. Inside the shield sits the ILI9486 controller, and that is what our own model simulates, written from the ILI9486 datasheet: the 320 x 480 frame memory, the 8-bit par ...
