Hello friends, I hope you all are doing great. Today, I am going to share the new TFT ST7735 Library for Proteus V1.0 . The 1.8" TFT is the little colour screen you find in so many Arduino kits: 128 x 160 pixels, 65,536 colours, a bright backlight and just a few SPI wires. It is the next step after a character LCD or a small OLED, when your project needs colours, graphs and icons. With this TFT ST7735 Library for Proteus , your sketch draws on a 1.8" TFT that behaves like the real one, including its two famous puzzles: the white screen and the wrong tab. This is our own model of the module, with the ST7735S controller written from its datasheet: the SPI interface bit by bit, every command with its parameters, the frame memory, the rotations, the colour order and the backlight. You get two ...
Hello friends, I hope you all are doing great. Today, I am going to share the new OLED Library for Proteus V1.0 . It brings all our OLED displays together in one library: the popular 0.96" OLED with its SSD1306 controller, the long and thin 0.91" 128x32 OLED , and the bigger 1.3" OLED with its SH1106 controller. You get one LIB file with 14 parts , one model file that runs them all, and a new demo in which a single Arduino UNO drives all three OLEDs at the same time. Each of these OLEDs already has its own library and its own article: the OLED SSD1306 Library for Proteus V1.0 , the OLED 128x32 Library for Proteus V1.0 and the OLED SH1106 Library for Proteus V1.0 . This OLED Library for Proteus puts the three of them in one package, the same way our LCD Library for Proteus V3.0 does for the ...
