Project Files of Analog Panel Meter Library for Proteus V1.0 (85C1 Voltmeter)
analog-panel-meter-tep-v1-0-0f60c25e2123407483fbc521300c4033.zip

Analog Panel Meter Library for Proteus V1.0
Analog Panel Meter Library for Proteus V1.0 comes as a ZIP archive of 10 files (1.2 MB, 2.7 MB unpacked) holding Proteus library files, simulation model DLLs, a Proteus simulation, an Arduino sketch and compiled HEX firmware.
- LIBProteus library
- DLLProteus model
- DSNProteus simulation
- INOArduino sketch
- HEXHEX firmware
Description
Analog-Panel-Meter-Library-for-Proteus-v1.0.zip with the moving-coil analog panel meter in Proteus (an 85C1-style voltmeter or ammeter by RANGE and UNIT, a needle with inertia and damping that averages an Arduino PWM; TEPMETER.LIB and TEPMETER.DLL), our Arduino UNO V4.0, the A4 demo project with its sketch and a README.
File Structure
4.1 KB201.9 KB78.1 KB883.5 KB325 KB29.8 KB22 KB883.5 KB325 KB16 KBGallery12 images from the tutorialOpen the tutorial
The circuit, the board and the results as they appear in Analog Panel Meter Library for Proteus V1.0 (85C1 Voltmeter). Open an image for its full size.












README
ANALOG PANEL METER LIBRARY FOR PROTEUS - V1.0 (a moving-coil 85C1-style meter with a real needle and a pop-up panel)
Designed by The Engineering Projects
www.TheEngineeringProjects.com
IMPORTANT LINKS
Article (read it first - pictures, step by step, every feature explained):
https://www.theengineeringprojects.com/2026/10/analog-panel-meter-library-for-proteus-v1-0.html
Report a bug or suggest a feature (our forum):
https://www.theengineeringprojects.com/forum/category/motor-driver-proteus-library
The demo runs on our Arduino UNO V4.0 (included) - working LEDs, RESET and a
built-in serial monitor, no Virtual Terminal to wire - its own article:
https://www.theengineeringprojects.com/2026/10/arduino-uno-library-for-proteus-v40.html
Support us (the libraries are free):
https://www.theengineeringprojects.com/donate
FILE STRUCTURE
Analog-Panel-Meter-TEP-v1.0/
|-- Proteus Library Files/
| |-- ArduinoV4TEP.LIB 201.9 KB TEP Arduino boards V4.0 (UNO) -> LIBRARY
| |-- TEPMETER.LIB 78.1 KB the library -> LIBRARY folder
|-- Proteus Model Files/
| |-- TEPARDUINO.DLL 883.5 KB the Arduino board model -> MODELS folder
| |-- TEPMETER.DLL 325.0 KB the model -> MODELS folder
|-- Proteus Simulation/
| |-- Analog-Panel-Meter-ArduinoUnoV4.pdsprj 29.8 KB the demo project
| |-- Panel_Meter_Demo.hex 22.0 KB the demo firmware
| |-- TEPARDUINO.DLL 883.5 KB copy of the board model
| |-- TEPMETER.DLL 325.0 KB copy of the model
|-- Arduino Code/
| |-- Panel_Meter_Demo/Panel_Meter_Demo.ino 4.1 KB the demo sketch (source of the .hex)
|-- README.txt ~17.1 KB this file
Total: 2.71 MB (unzipped). The C++ source code of the models is not included.
WHAT IS IT?
A simulation model of the classic analog panel meter (the 85C1 type): a light
coil on jewel pivots in the field of a permanent magnet, two hair springs and
a needle over a 90 deg scale - in effect a tiny motor that turns against a
spring. Our own model, not a voltmeter probe with a picture:
* The terminals are the meter's real resistance in the circuit: a voltmeter
is the 1 mA movement with its series resistor (1000 ohm per volt - the
0 - 5 V meter is 5000 ohm), an ammeter is the movement with a shunt (100 mV
at full scale, 75 mV for amps). Properties RANGE and UNIT (V, mA, uA, A).
* The needle has inertia, springs and damping: about 10 % overshoot after a
step, inside 1 % of the reading in about 1 s - the behaviour of a class
2.5 meter. End stops at -3 and 93 deg.
* The needle shows the AVERAGE current. An Arduino's analogWrite() (490 Hz
on D9) reads as a steady voltage: 5 V x the duty. A slow PWM (a few hertz)
makes the needle follow the pulses - the meter names it.
* The mistakes it names: no current, a reversed meter (the needle pushes
left against its stop), over the range (pegged on the right stop), an
overload (more than twice the full-scale current), a PWM too slow to
average.
* The zero screw (the pop-up's toolbar) moves the needle's rest point like
the screw on the real meter; a click on the glass taps it.
The symbol: the black 85C1 case, the cream scale behind the glass (numbered
from 0 to RANGE, five small divisions each) with the unit, the black needle
from the pivot under the dark nose with the zero screw; the + terminal (red
stud) on top, the - terminal (black stud) on the right. The plate, the current
LED I (green while the current flows into +, red when it flows into -) and the
strip under the plate (READING, CURRENT, PERCENT and OPEN PANEL) are
TEP additions; the real meter has none of them.
ONE DEVICE (search "panel meter" or "PANELMETER" in Pick Devices):
PANELMETERTEP "Analog Panel Meter V1.0" (category Electromechanical >
Panel Meters), model TEPMETER.DLL
The pop-up panel "TEP Analog Panel Meter" opens at Run (and with OPEN PANEL
on the strip) - the look of the TEP Serial Monitor. Tabs Meter, Graphs,
Event log and Check; gear and ? icons for Settings and Help; the palette
icon switches the theme:
Meter the state in big letters (SHOWING 3.30 V / MOVING / SHAKING /
PEGGED / REVERSED / NO CURRENT), the dial - the needle and an
orange mark where the current asks it to be -, the live values
(reading, needle %, the average current and voltage, the PWM,
the needle's ripple, the last move's overshoot and settling
time) and the terminal voltage over the last 20 ms. The
toolbar: the zero screw (- / reset / +) and Tap the glass.
Graphs the needle and what the current asks (in the meter's unit) and
the current over the last 2, 6 or 15 s. Live / Freeze.
Event log the current on / off, every move ("SHOWING 3.28 V (65.7 %) -
settled in 0.96 s from 0.01 V, overshoot 9.1 % of the step"),
the PWM seen, the zero screw, taps, the warnings; filters All /
Moves / Warnings, Pause, Clear
Check Good for: a needle that does not move, goes the wrong way, sits
on its end stop, shakes or reads wrong - the connection, the
range, overload, PWM, the response and the meter itself, each
with a verdict (green = fine, amber = check, red = wrong)
Settings theme, text size, open at Run, window size
Help report a bug, suggest a feature, article, updates, donate,
forum; Copy diagnostics for a bug report
TEST STATUS
V1.0: verified in Proteus 8.5 on 28 Oct 2026 (the demo project as shipped: an
A4 sheet, an Arduino UNO V4.0 with its built-in monitor, the 0 - 5 V meter on
D9, RV1 on A0; the pop-up open).
What the runs showed (the needle as the model computed it):
* The project loads and starts cleanly. RV1 at 66 %: "Pot 676 -> PWM
169/255 = 3.31 V"; the needle settled at 3.30 V (66.0 %) in 0.96 s with a
9.1 % overshoot; PWM 490 Hz, 66 % duty seen; the needle's ripple 0.01 % of
the scale; the current 0.661 mA on average (0.996 mA in each pulse).
* step: 0 V, then 5 V at once - 4.98 V (99.6 %), settled in 0.79 s; the
overshoot was only 3.8 % because the needle ran into its 93 deg end stop.
* volts 2.5: PWM 128/255, the needle at 2.50 V, PWM 490 Hz 50 %.
* slow 4: a 4 Hz software PWM at the same duty - SHAKING, the needle swings
0.39 V (7.85 % of the scale), "the needle shakes by 0.40 V at 4.0 Hz - too
slow to average". knob: back to 3.30 V, the ripple gone.
* The zero screw +1.0 deg: the needle at 3.36 V (+1.11 % of the scale);
reset: 3.30 V. A tap on the glass: the needle jumped and settled back.
* The pop-up: Meter, Graphs (2 / 6 / 15 s), Event log, Check - all four
pages followed the run.
Plus automatic checks on a PC, 0 failed: 16 on the meter (a 3.3 V step
behind a pin's 25 ohm reads 3.283 V, 9.2 % overshoot - the ideal second-
order value is 9.5 % -, settled in 0.97 s; analogWrite 168 at 490 Hz reads
3.278 V with a 0.011 % ripple and is seen as 490.2 Hz, 65.9 %; a 4 Hz PWM
shakes the needle 7.9 % of the scale; 6 V on the 5 V meter pegs it; -2 V
reverses it; 11 V is an overload of 2.2 x; the zero screw +2 deg; a 0 - 20
mA ammeter is 5 ohm and reads 10 mA); 3 on the pop-up pages rendered; the
demo project read back from disk (48 checks: devices, pins, wires, labels,
no wire through a part, no wire crossing).
INSTALLATION (about 2 minutes)
1. Close Proteus. Extract the WHOLE ZIP to a normal folder (e.g. Desktop).
2. Copy everything in "Proteus Library Files" (TEPMETER.LIB, and our Arduino
library V4.0, ArduinoV4TEP.LIB, with the ARDUINO UNO V4.0 used by the demo)
to the LIBRARY folder of Proteus, for example:
C:\Program Files (x86)\Labcenter Electronics\Proteus 8 Professional\LIBRARY
(on some PCs: C:\ProgramData\Labcenter Electronics\Proteus 8 Professional\
LIBRARY - use the folder that already holds Proteus's own .LIB files).
3. Copy TEPMETER.DLL and TEPARDUINO.DLL from "Proteus Model Files" to the
MODELS folder (...\Proteus 8 Professional\MODELS).
ArduinoV4TEP.LIB and TEPARDUINO.DLL are the files of our Arduino Library
V4.0 - if you have it, they are the same.
4. Delete TEPMETER.IDX from the LIBRARY folder if it is there (Proteus makes a
new index).
5. Start Proteus. In Pick Devices (P) search "PANELMETER".
RUN THE DEMO
"Proteus Simulation\Analog-Panel-Meter-ArduinoUnoV4.pdsprj" (an A4 sheet) -
keep the .hex file and the two DLLs beside the project.
ARD1: Arduino UNO V4.0 running Panel_Meter_Demo.hex, its serial monitor
built in (window "TEP Arduino UNO - ARD1").
PM1: the 0 - 5 V panel meter - + on D9 (by the net label D9 above both
parts), - on ground.
RV1: a 10k potentiometer (POT-HG) on A0 - it sets the needle.
1. Press Run. The monitor and the meter's pop-up open (move them aside -
they open over the schematic). The needle swings to the pot's voltage
(RV1 at 66 %: 3.30 V), overshoots a little and settles.
2. Click RV1's arrows: the needle follows.
3. Type in the monitor and press Send: volts 3.3, pwm 128, step, slow 4,
sweep, knob - see THE DEMO SKETCH.
4. On the pop-up: turn the zero screw, tap the glass, and watch the Graphs
and the Event log.
Closed a window? The monitor: click the UNO's USB port; the pop-up: OPEN PANEL.
WIRING (the same in Proteus and on a real board)
Panel meter Arduino UNO
+ D9 (any PWM pin: analogWrite gives 490 Hz on D9)
- GND
Potentiometer the ends to 5V and GND, the wiper to A0
A 0 - 5 V meter (a 1 mA movement with its 5 kohm resistor) takes 1 mA at full
scale: the pin drives it directly. In the sketch:
analogWrite(9, 168); // 168 / 255 x 5 V = 3.29 V on the meter
REAL HARDWARE:
* Check what is inside your meter: a "0 - 5 V" meter has its resistor built
in; a bare 1 mA or 100 uA movement needs a series resistor of (5 V / its
full-scale current) minus its own resistance - without it the needle slams
into the end stop and the coil can burn.
* Ammeters have a shunt of a fraction of an ohm: never put one straight
across a supply.
* Analog meters are calibrated upright or flat, as the dial says; set the
zero with the screw before you trust them.
THE DEMO SKETCH ON THE SERIAL MONITOR (Panel_Meter_Demo V1.0, 9600 baud)
volts 3.3 show 3.3 V and stay (the pot is ignored until knob)
pwm 128 analogWrite(9, 128) directly (0 - 255)
step 0 V for 1.5 s, then 5 V at once: the overshoot and settling
slow 4 the same duty as a 4 Hz software PWM: the needle shakes
sweep 0 to 5 V and back in about 4 s
knob follow the pot on A0 again
help the list
EXPECTED MONITOR OUTPUT
Analog panel meter demo - The Engineering Projects
Meter + on D9 (PWM), - on GND: 0 - 5 V. The pot on A0 sets the needle.
Commands: volts 3.3 | pwm 128 | step | slow 4 | sweep | knob | help
Pot 676 -> PWM 169/255 = 3.31 V
PROPERTIES (double-click the part > Edit Properties)
RANGE the full-scale value (default 5); the scale's numbers follow it
UNIT V (default), mA, uA or A - V makes a voltmeter of 1000 ohm per volt,
the others an ammeter: 100 mV across it at full scale (75 mV for A)
Try RANGE 3 in the demo: above 60 % of the pot the needle pegs on its stop.
Every run starts again from the properties. The demo's UNO (ARDUINO UNO V4.0):
PROGRAM Panel_Meter_Demo.hex, MONITOR YES (the built-in monitor), BAUD 9600,
AUTOOPEN YES, BOOTLOADER YES.
LINKS.INI (OPTIONAL)
The Help page cards of the pop-up open web pages. To point them somewhere else
without a new DLL, put a text file named links.ini next to TEPMETER.DLL with
lines KEY=URL, for example:
ARTICLE=https://www.theengineeringprojects.com/...
Keys: WEBSITE, FORUM, BUG_REPORT, FEATURE_REQUEST, ARTICLE, USER_GUIDE,
UPDATE_CHECK, DONATE. Only http:// and https:// links are used; lines starting
with # are comments.
TROUBLESHOOTING
* The needle never moves (NO CURRENT): + or - is not connected, or the pin is
not an output / never written.
* The needle pushes left against its stop (REVERSED): + and - are swapped.
* The needle sits on the right stop (PEGGED): the value is over RANGE - a
bigger RANGE, or a divider in front of the meter.
* The needle shakes (SHAKING): the PWM is too slow for it - use analogWrite
(490 Hz) or anything above about 50 Hz.
* The reading is a little off: check the zero (the pop-up's zero screw) and
the PWM's duty (the Check page shows both).
* The part is not simulated / the needle never turns: TEPMETER.DLL is missing
from MODELS and from the project folder. No UNO / no monitor window:
TEPARDUINO.DLL is missing, or click the UNO's USB port.
* The pop-up does not appear: click OPEN PANEL on the strip, or turn "Open the
panel at Run" on its Settings page back on.
BUG REPORTS AND FEATURE REQUESTS
Please post them in our forum with a screenshot, the Serial Monitor text, the
simulation log and the pop-up's Copy diagnostics text:
https://www.theengineeringprojects.com/forum/category/motor-driver-proteus-library
SUPPORT US
This library is free. If it saves you time, please support our work:
https://www.theengineeringprojects.com/donate
WEBSITE
https://www.theengineeringprojects.com/
LICENCES AND THIRD-PARTY NOTES
* The meter model (TEPMETER.DLL), the symbol and artwork and the Arduino
Library V4.0 (ArduinoV4TEP.LIB / TEPARDUINO.DLL, with its built-in TEP Serial
Monitor Advance) are made by The Engineering Projects. The model is an
independent implementation written from the typical data of moving-coil
panel meters. The model uses only standard Windows libraries; no Visual C++
redistributable is needed. The C++ source code is not included.
* Arduino UNO V4.0 (ArduinoV4TEP.LIB / TEPARDUINO.DLL, our Arduino Library
V4.0 - its microcontroller is Proteus's own AVR model): The Engineering
Projects, https://www.theengineeringprojects.com/2026/10/arduino-uno-library-for-proteus-v40.html
* The potentiometer is Proteus's own POT-HG.
* The .hex file is built from the demo sketch and the Arduino AVR core 1.8.6,
which includes LGPL-licensed code; its source code is available at
https://github.com/arduino/ArduinoCore-avr/tree/1.8.6
* Proteus is a product of Labcenter Electronics and is not included. Arduino is
a trademark of Arduino SA. This library is not made or endorsed by any meter
maker, Arduino or Labcenter.
REBUILDING THE FIRMWARE (OPTIONAL)
The HEX file is supplied; Arduino IDE is not needed to run the demo. To edit the
sketch, open Arduino Code\Panel_Meter_Demo\Panel_Meter_Demo.ino, select Arduino
Uno and use Sketch > Export Compiled Binary. Replace the simulation's .hex with
the exported HEX. The sketch needs 8,004 bytes of flash (25 % of the UNO) and
289 bytes of RAM.
MODEL SCOPE AND LIMITS
Modelled: the terminal resistance (a voltmeter's 1000 ohm per volt, an
ammeter's shunt), the movement's torque from the current, the springs, the
inertia, the damping (about 10 % overshoot, about 1 s to settle), the pivots'
friction, both end stops, the zero screw, a tap on the glass.
How it runs: the terminals are a resistance in the analog circuit; at every
accepted point the needle follows the solved current in 0.2 ms steps. The
analog step is held to 2 ms while the needle moves (10 ms at rest); a PWM's
edges add their own points.
Not modelled: AC meters (a moving-iron or rectifier movement), the scale's
own non-linearity, temperature, the movement's back-EMF (microvolts here),
the spread from meter to meter.
VERSION
TEP Analog Panel Meter library V1.0 (Oct 2026). Device PANELMETERTEP
(TEPMETER.LIB / TEPMETER.DLL). Demo sketch Panel_Meter_Demo V1.0. Demo board:
ARDUINO UNO V4.0 (TEP Arduino Library V4.0) with its built-in serial monitor.Development1 release
-
V1.0Analog Panel Meter Library for Proteus V1.0this page
V1.0 is the only release in the Download Center so far. When a newer version is published, it appears above with its own download page.
Installation8 steps
From the download to a working project, in order. The steps follow what the package contains.
You will need
- Proteus Design SuiteProteus 8 or newer (Labcenter), on Windows
- Arduino IDE1.8 or 2.x, with the board of the tutorial chosen under Tools → Board
- Any archive toolWindows, macOS and Linux extract ZIP files on their own
Steps
- 1
Extract the archive
Right-click analog-panel-meter-tep-v1-0-0f60c25e2123407483fbc521300c4033.zip and choose Extract All (or open it with 7-Zip or WinRAR) into a folder you can find again. Keep its folder structure (Analog-Panel-Meter-TEP-v1.0) as it is.
- 2
Copy the library files into Proteus
Move ArduinoV4TEP.LIB and TEPMETER.LIB and the files into the LIBRARY folder of your Proteus installation: C:\Program Files (x86)\Labcenter Electronics\Proteus 8 Professional\LIBRARY for Proteus 8, or the matching Proteus 7 folder. Older versions keep it under ProgramData\Labcenter Electronics. If Proteus is open, close it first.
- 3
Add the simulation model
Copy TEPARDUINO.DLL and TEPMETER.DLL into the MODELS folder next to LIBRARY, so the component can run, not only be drawn.
- 4
Restart Proteus and place the component
Start Proteus, open a schematic, press P (Pick Devices) and search for the component by the name used in the tutorial. It appears with its pins ready to wire.
- 5
Open the sketch in the Arduino IDE
Open Panel_Meter_Demo.ino, select your board and port under Tools, then Verify. Sketch → Export Compiled Binary writes the HEX file a simulation needs.
- 6
Load the HEX file
In Proteus double-click the microcontroller, set Program File to Panel_Meter_Demo.hex and run the simulation. For real hardware, flash the same file with your programmer.
- 7
Open the example simulation
Open Analog-Panel-Meter-ArduinoUnoV4.pdsprj in Proteus to see the wiring exactly as in the tutorial. Check the controller's Program File path, then press Play.
- 8
Follow the tutorial
Analog Panel Meter Library for Proteus V1.0 (85C1 Voltmeter) explains every connection and setting in order; keep it open beside the files while you build.
FAQs9 questionsContact TEP
How do I download Analog Panel Meter Library for Proteus V1.0?
Wait for the 30-second guest countdown on this page, then press the download button; the file comes straight from our storage. Members who are logged in skip the wait. If the browser opens the file instead of saving it, use its Save as option. The download link is made for you when the countdown ends and works for 15 minutes; a saved or shared link stops working, so share this page instead.
What is inside the archive?
Analog Panel Meter Library for Proteus V1.0 comes as a ZIP archive of 10 files (1.2 MB, 2.7 MB unpacked) holding Proteus library files, simulation model DLLs, a Proteus simulation, an Arduino sketch and compiled HEX firmware. Open the File Structure tab for the full list of 10 files.
What should I do if the download does not start?
Check the browser's download list first; an ad blocker or a company firewall can also hold it back, so try another browser or network. If the file arrives incomplete, download it again. For an installation problem, read the Install tab or tell us in the comments with your software version and the exact error message.
Is this file free?
Yes. Every file in the TEP Download Center is free for learning, personal and student projects. If you share it, link back to this page or the tutorial so others find the latest version.
How do I check that the file arrived complete?
Compare its SHA-256 with the one on this page, c5a852f2075cce2b7f99f96824079aaad862e59186c423e0aff3205dd8495a68. In PowerShell run Get-FileHash "analog-panel-meter-tep-v1-0-0f60c25e2123407483fbc521300c4033.zip"; on macOS or Linux run shasum -a 256 "analog-panel-meter-tep-v1-0-0f60c25e2123407483fbc521300c4033.zip". The same value means the file is exactly the one in our storage; a different one means the download broke off, so download it again.
Do I need WinRAR to open the ZIP file?
No. Windows, macOS and Linux open ZIP archives on their own (Extract All, or double-click). WinRAR and 7-Zip work too. Extract the whole archive before using the files.
Where do I put the LIB and IDX files?
Both files go into the LIBRARY folder of your Proteus installation (Proteus 8: C:\Program Files (x86)\Labcenter Electronics\Proteus 8 Professional\LIBRARY; Proteus 7 has the same folder under its own name). Restart Proteus afterwards and search for the component with P.
Which Proteus version does the library need?
The tutorial names the Proteus version the library was made and tested with. Most TEP libraries work in Proteus 7 and Proteus 8; if the component does not appear after a restart, check that both the LIB and the IDX file were copied and that Proteus was fully closed while copying.
How do I get the HEX file into the simulation?
Compile the sketch in the Arduino IDE (Sketch → Export Compiled Binary gives you the HEX next to the sketch), then in Proteus double-click the board, set Program File to that HEX and run.
Members skip the wait. Log in or join TEP.
- 0Total downloads
- 4%Popularity
- ProteusCategory
- 0Comments
- ssyedzainnasirUploaded by
- 30 Oct 2026Uploaded at
c5a852f2075cce2b7f99f96824079aaad862e59186c423e0aff3205dd8495a68

















Comments
0
