Project Files of BBC micro:bit V2 Library for Proteus: LED Matrix and Radio Game

BBC MICRO:BIT V2 LIBRARY FOR PROTEUS - V1.0 (YOUR MICRO:BIT SKETCH, THE 5 X 5 LED MATRIX, BUTTONS A / B AND THE RADIO)
Designed by The Engineering Projects
www.TheEngineeringProjects.com

IMPORTANT LINKS
Article (read it first - pictures, step by step, every feature explained):
  https://www.theengineeringprojects.com/2026/10/bbc-microbit-v2-library-for-proteus.html
Report a bug or suggest a feature (our forum):
  https://www.theengineeringprojects.com/forum/category/bbc-microbit-v2-proteus-library
The demo's parts are our libraries (included) - their articles:
  ESP-01S:
    https://www.theengineeringprojects.com/2026/10/esp-01s-library-for-proteus.html
  WS2812B NeoPixel ring:
    https://www.theengineeringprojects.com/2026/10/ws2812b-neopixel-library-for-proteus-v1-0.html
  Laptop and phone:
    https://www.theengineeringprojects.com/2026/10/laptop-wifi-monitor-library-for-proteus.html
    https://www.theengineeringprojects.com/2026/10/mobile-wifi-monitor-library-for-proteus.html
Support us (the libraries are free):
  https://www.theengineeringprojects.com/donate

FILE STRUCTURE
BBC-microbit-V2-TEP-v1.0/
|-- Proteus Library Files/
|   |-- TEPESP01S.LIB                                    18.5 KB   the ESP-01S (demo), to LIBRARY
|   |-- TEPLAPTOP.LIB                                    39.5 KB   the laptop (demo), to LIBRARY
|   |-- TEPMICROBIT.LIB                                  24.6 KB   the BBC micro:bit V2, to LIBRARY
|   |-- TEPMOBILE.LIB                                    13.1 KB   the phone (demo), to LIBRARY
|   |-- TEPWS2812.LIB                                    1.59 MB   the WS2812B ring (demo), to LIBRARY
|-- Proteus Model Files/
|   |-- TEPNET.DLL                                       2.58 MB   the board + monitors + network, to MODELS
|   |-- TEPWS2812.DLL                                   312.5 KB   the WS2812B ring, to MODELS
|-- Arduino Code/
|   |-- Microbit_Reaction_Host/Microbit_Reaction_Host.ino   13.2 KB   the demo sketch
|   |-- Microbit_Reaction_Player/Microbit_Reaction_Player.ino    3.2 KB   the demo sketch
|   |-- TEP Boards for Proteus/hardware/                843.7 KB   the Arduino IDE add-on 1.36.0 (195 files)
|-- Proteus Simulation/
|   |-- Microbit_Reaction_Host.hex                       50.0 KB   the demo sketch (U1)
|   |-- Microbit_Reaction_Player.hex                     29.1 KB   the demo sketch (U2)
|   |-- Microbit-Reaction-Game.pdsprj                    34.9 KB   the demo: a two-player reaction game over the radio
|   |-- TEPNET.DLL                                       2.58 MB   copy of the model
|   |-- TEPWS2812.DLL                                   312.5 KB   copy of the model
|-- README.txt                                          ~14.6 KB   this file
Total: 8.43 MB (unzipped). The source code of the models is not included.

WHAT IS IT?
Proteus 8 has no Nordic nRF52833 model, so this is NOT a real nRF52833. It is the BBC micro:bit V2 - the 52 x 42 mm
black board with the 5 x 5 red LED matrix, buttons A and B, the gold touch logo, the micro-USB and the edge connector
with its five big rings (0, 1, 2, 3V, GND) - that runs YOUR micro:bit Arduino sketch in Proteus:
  * You write a normal micro:bit sketch with the micro:bit's pin numbers (P0 .. P20: digitalWrite(2, HIGH),
    analogRead(0), PIN_BUTTON_A, PIN_BUTTON_B, Serial, Serial1, Wire, SPI ...) and compile it in the Arduino IDE with
    our board package "TEP Boards for Proteus" 1.36.0 (in Arduino Code - see INSTALLATION).
  * Inside the board, Proteus's own ATmega2560 model runs the compiled sketch at 16 MHz; our model (TEPNET.DLL) wraps
    it: the edge pins, 3.3 V logic, analogRead 0 .. 1023 for 0 .. 3.3 V on P0, P1 and P2, buttons A and B (click them),
    the power LED and the built-in serial monitor on the USB (Serial).
  * The LED matrix: Adafruit_Microbit's names (Adafruit_Microbit_Matrix microbit; microbit.begin(); microbit.show(
    microbit.HEART); microbit.print("HI"); microbit.scrollText("GO"); drawPixel, fillScreen, clear; the icons HEART,
    YES, NO, HAPPY, SAD, ARROW_UP ...). The board model draws the 25 LEDs on the board.
  * The radio: our MicrobitRadio library with MicroPython's names (Radio.on(); Radio.config(23); Radio.send("GO");
    Radio.available(); Radio.receive(); Radio.rssi()). Messages up to 32 bytes go to every other micro:bit of the design
    on the same group and channel - put two, three or more micro:bits on one sheet and they talk.
TEP additions: the micro-USB opens the serial monitor; the matrix and the power LED glow in the simulation.
For Wi-Fi, put an ESP-01 / ESP-01S on Serial1 (P0 RX / P1 TX) and talk to it with AT commands, as the demo does.
Limits (say them before you start): 16 MHz, 8 KB of RAM (the real nRF52833: 64 MHz, 128 KB), the nRF52833's own
registers are not there - write Arduino code, not registers. See MODEL SCOPE AND LIMITS.

ONE DEVICE (search "MICROBIT" in Pick Devices):
  BBC MICROBIT V2  "BBC micro:bit V2" V1.0 (Microprocessor ICs > micro:bit), prefix U, model TEPNET.DLL. The serial
  monitor (115200 baud) has Monitor, Plotter and Board tabs (the Board tab: the power LED, the RESET key, button A,
  every pin). Like every TEP window it has no Windows title bar.
The same TEPNET.DLL also runs our other sketch boards, the ESP-01S and the Laptop / Mobile WiFi Monitors; it replaces
any older TEPNET.DLL (keep only this newest one in MODELS).

TEST STATUS
V1.0: verified in Proteus 8.5 on 27 Oct 2026 with the demo project as shipped. What the Proteus run showed:
* Microbit-Reaction-Game: both matrices showed a happy face; U1's monitor printed "Joining TEP-WiFi... connected",
  "Scoreboard: http://192.168.1.103/" and "Press B (or START on the page) for a round"; U2's monitor "Waiting for the
  host on radio group 23"; the ESP-01S's pop-up: joined, the server on port 80. Each board's monitor showed only its own
  lines (two micro:bits in one design, each with its own USB serial and buttons).
* The laptop (192.168.1.21) and the phone (192.168.1.41) opened http://192.168.1.103/ (HTTP 200): the score, the last
  result, the times, START, RESET, REFRESH and JSON.
* Round 1 (START in U1's monitor): both matrices counted 3 - 2 - 1, the ring filled red then amber; GO: the arrow on
  both, the ring green; A on U2 then A on U1 (the monitors' Board tab keys): "Player 2: 302 ms (RSSI -46 dBm)",
  "Player 1: 433 ms", "Winner: round 1: player 2 in 302 ms - score 0 : 1"; YES on U2, NO on U1, the ring red. U2's
  monitor: "Radio: R", "Radio: G", "Pressed after 302 ms", "Radio: W2", "I won! Wins 1 of 1".
* Round 2: player 1 first - "Winner: round 2: player 1 in 319 ms - score 1 : 1", YES on U1 (the PWR LED lit), the ring
  blue. Round 3 from START on the phone ("Page: /start"): A on U1 during the countdown (a false start), then A on U2
  after GO - "Winner: round 3: player 2 (a false start) - score 1 : 2", the ring red; the pages: 1 : 2, 3 rounds.
* About 45 s of simulation in about 6.5 minutes with both monitors, the ESP-01S's and the ring's pop-ups and both tools
  open; no errors.

INSTALLATION (about 3 minutes)
1. Close Proteus. Extract the WHOLE ZIP to a normal folder (e.g. Desktop).
2. Copy everything in "Proteus Library Files" to the LIBRARY folder of Proteus, for example:
     C:\Program Files (x86)\Labcenter Electronics\Proteus 8 Professional\LIBRARY
   (on some PCs: C:\ProgramData\Labcenter Electronics\Proteus 8 Professional\LIBRARY). TEPMICROBIT.LIB is the board;
   the others are the demo's parts: TEPESP01S.LIB, TEPWS2812.LIB, TEPLAPTOP.LIB and TEPMOBILE.LIB.
3. Copy the DLLs from "Proteus Model Files" (TEPNET.DLL, TEPWS2812.DLL) to the MODELS folder
   (...\Proteus 8 Professional\MODELS) - replace an older TEPNET.DLL (this one is the first that knows the micro:bit).
4. Delete TEPMICROBIT.IDX from the LIBRARY folder if it is there.
5. The Arduino IDE (only to compile your own sketches - the demo has its HEX files): copy the folder
   "Arduino Code\TEP Boards for Proteus\hardware" into your sketchbook folder (normally Documents\Arduino), so that
   Documents\Arduino\hardware\tep\avr\boards.txt exists (replace an older copy); restart the IDE. The Arduino AVR Boards
   platform must be installed (it comes with IDE 1.8.x; in IDE 2.x install "Arduino AVR Boards" from the Boards Manager
   once). Tools > Board > TEP Boards for Proteus > BBC micro:bit V2 (TEP Proteus). Adafruit_Microbit and MicrobitRadio
   come with the package; for the demo also install "Adafruit NeoPixel" from the Library Manager.
6. Start Proteus. In Pick Devices (P) search "MICROBIT".

RUN THE DEMO
Keep the .hex files and the DLLs beside the project in "Proteus Simulation".
Microbit-Reaction-Game.pdsprj - a two-player reaction game over the radio (group 23). U1 the host micro:bit
(Microbit_Reaction_Host.hex, player 1) runs the game: U3 = the ESP-01S (TXD to P0, RXD to P1, Serial1 at 115200 baud)
serves the scoreboard, NEO1 = the 12-LED WS2812B ring (Advance; DIN on P2) shows the countdown, GO and the winner.
U2 the player micro:bit (Microbit_Reaction_Player.hex, player 2) has nothing wired: the radio is its only link.
PC1 the Laptop WiFi Monitor and MOB1 the Mobile WiFi Monitor open http://192.168.1.103/.
Press Run. Both matrices show a happy face, the ESP-01S joins TEP-WiFi and U1's monitor prints the scoreboard's address.
A round: press B on U1 (click it on the board), tap START on the page or type START in U1's monitor.
  * both matrices count down 3 - 2 - 1 (the ring fills red, then amber), then after a random 1 - 3 s wait: GO - an
    arrow on both matrices and the ring all green
  * press A (click it on the board, or the A key on the monitor's Board tab): the first player wins the round; A before
    GO is a false start and loses it; nobody in 3 s: nobody wins
  * both matrices show YES (the winner) or NO, the ring lights in the winner's colour (player 1 blue, player 2 red)
The radio messages: R (a round starts), G (go), T<ms> (player 2's time), F (player 2's false start), W1 / W2 / W0 (the
winner). U1's monitor prints every round ("Player 2: 412 ms (RSSI -50 dBm)", "Winner: round 1: player 2 in 412 ms");
it takes START, RESET, STATUS, HELP and AT commands. U2's monitor prints every message it hears.
The page shows the score, the last result, the times and the best time, with START, RESET, REFRESH and /json.
The modules' supplies: in the demo the ESP-01S's VCC and the ring's 5V go to Proteus' power rail (power terminals) -
their models read the supply as a digital level, which the board's 3V (an analog source) does not give them; on a real
micro:bit the ESP-01S needs its own 3.3 V supply (it draws more than the board's regulator gives) and the ring a 5 V
supply, the grounds joined. Closed the monitor? Click the board's micro-USB.

THE PINS (the label on the board, what it can do in the simulation)
  0 / 1 / 2 (rings)  P0 / P1 / P2: GPIO, analogRead 0 .. 1023 for 0 .. 3.3 V, interrupt, analogWrite; P0 / P1 are also
                     Serial1 RX / TX
  P8, P12            GPIO, interrupt, analogWrite
  P13 / P14 / P15    SPI SCK / MISO / MOSI, GPIO
  P16                SS, GPIO
  P19 / P20          Wire SCL / SDA (I2C), GPIO
  3V, GND (rings)    3.3 V and ground
  P3, P4, P6, P7, P9, P10 (the matrix on the real board) and P5 / P11 (buttons A / B) are drawn on the connector, not
  brought out: the matrix and the buttons are the board model's.
Serial is the USB (the board's monitor), not P0 / P1. The pins are 3.3 V logic, as on the real micro:bit.

PROPERTIES (double-click the board > Edit Properties)
  PROGRAM   the sketch's HEX (Arduino IDE: Sketch > Export Compiled Binary with BBC micro:bit V2 (TEP Proteus))
  MONITOR   YES = the built-in serial monitor on the USB (Serial);  BAUD  its speed (115200, or AUTO)
  AUTOOPEN  YES = the monitor window opens at Run (the demo: YES)
Several micro:bits in one design are fine: each keeps its own USB serial and buttons, and all share one radio air.

TROUBLESHOOTING
* Nothing happens at Run: the HEX was not built with TEP Boards for Proteus - select BBC micro:bit V2 (TEP Proteus) and
  export the binary again.
* The other micro:bit hears nothing: both need Radio.on() and the same Radio.config(group) - and the same channel if
  you set one (7 by default).
* "Joining TEP-WiFi... FAILED": the sketch's SSID / password differ from the ESP-01S's WIFISSID / WIFIPASS.
* No page: the ESP-01S's TXD to P0, RXD to P1, VCC on the power terminal; the address is in U1's monitor.
* The ring stays dark: DIN on P2, its 5V on the power terminal, ring.begin() and ring.show().
* An integer goes wrong above 32767: int is 16 bits here (on the real nRF52833 it is 32 bits) - use long.
* The page shows old values: tap REFRESH (the monitors do not reload by themselves).

BUG REPORTS AND FEATURE REQUESTS
Please post them in our forum with a screenshot and the Serial Monitor text:
  https://www.theengineeringprojects.com/forum/category/bbc-microbit-v2-proteus-library

LICENCES AND THIRD-PARTY NOTES
* The board model and the network (TEPNET.DLL, which also runs the ESP-01S), the symbols and artwork (TEPMICROBIT.LIB,
  TEPESP01S.LIB, TEPLAPTOP.LIB, TEPMOBILE.LIB) and the ring's model (TEPWS2812) are made by The Engineering Projects.
  The board's processor is Proteus's own ATmega2560 model. The source code of the models is not included.
* TEP Boards for Proteus (Arduino Code): its core, the variants and the EEPROM, SPI and Wire libraries are modified
  copies of the Arduino AVR core 1.8.6 - GNU Lesser General Public License 2.1 (LGPL 2.1, the text:
  LICENSE-LGPL-2.1.txt); its Adafruit_Microbit (written by us with Adafruit's names) and MicrobitRadio (MicroPython's
  names) libraries, its other libraries and our core files are MIT (LICENSE-MIT.txt).
* The demo sketch uses Adafruit NeoPixel (LGPL 3, Adafruit Industries) from the Library Manager - not included; the
  .hex files are included.
* Proteus is a product of Labcenter Electronics and is not included. BBC and micro:bit are trademarks of the BBC and
  the Micro:bit Educational Foundation; nRF52833 is a name of Nordic Semiconductor. This library is not made or endorsed
  by them, by Adafruit or by Labcenter.

REBUILDING THE FIRMWARE (OPTIONAL)
The HEX files are supplied. Install TEP Boards for Proteus (INSTALLATION step 5) and Adafruit NeoPixel, open Arduino
Code\Microbit_Reaction_Host and Arduino Code\Microbit_Reaction_Player, select BBC micro:bit V2 (TEP Proteus) and use
Sketch > Export Compiled Binary for each. For real micro:bits the matrix code compiles with Adafruit's Adafruit_Microbit
library (the nRF5 boards package); the radio there is a different library (MicroPython's radio module, or Adafruit's
BLE) - our MicrobitRadio is the Proteus radio.

MODEL SCOPE AND LIMITS
Modelled: the micro:bit's edge pins on a hidden ATmega2560 (Proteus's AVR model, 16 MHz, 3.3 V); digital I/O, analogRead
(P0, P1, P2) 0 .. 1023 for 0 .. 3.3 V, PWM (analogWrite) and attachInterrupt on any pin through the board model; buttons
A and B (a click is a press of at least 0.12 s), the 5 x 5 LED matrix (on / off per LED), the power LED; Serial (the
USB, the board's monitor), Serial1 on P0 / P1, Wire on P19 / P20, SPI on P13 .. P16, EEPROM; the radio between the
micro:bits of the design (groups, channels, power 0 .. 7 as the RSSI the others see, 32-byte messages, a queue of 4).
Not modelled: the nRF52833 itself (64 MHz, 128 KB RAM, Bluetooth LE), the matrix's brightness levels, the
accelerometer and compass, the speaker and the microphone, the touch logo, the RESET button on the back, the edge
connector's P3 .. P7, P9 .. P11 as pins, MicroPython and MakeCode (this board runs Arduino sketches). The power LED is
drawn at the top edge (on the real board it is on the back). The simulation runs below real time.

VERSION
TEP BBC micro:bit V2 library V1.0 (Oct 2026). Device BBC MICROBIT V2 (TEPMICROBIT.LIB / TEPNET.DLL), TEP Boards for
Proteus 1.36.0 (adds the micro:bit V2, Adafruit_Microbit and MicrobitRadio). Demo sketches Microbit_Reaction_Host and
Microbit_Reaction_Player V1.0. Demo parts: ESP-01S WIFI MODULE, the WS2812B 12-LED ring (the Advance version),
LAPTOP WIFI MONITOR and MOBILE WIFI MONITOR.
