ESP32 Library for Proteus

ESP32 Library for Proteus comes as a ZIP archive of 3 files (11.6 KB, 62.9 KB unpacked) holding Proteus library files and a Proteus simulation.

LIBProteus library
IDXProteus library index
DSNProteus simulation

Description

This is the download page of ESP32 Library for Proteus, the file package of the tutorial ESP32 Library for Proteus, published on The Engineering Projects in July 2023. Here you get the ZIP file (11.6 KB) with the Proteus library files (LIB and IDX) and a ready Proteus simulation, the list of files it contains, the README when there is one, and the installation steps in order.

What this library is

ESP32 Library for Proteus adds ESP32 to Proteus as a schematic component: once installed, the part appears in the Pick Devices list under its own name, with its real pin layout, and can be placed and wired like any built-in device. It is a symbol-and-footprint library: it draws and routes the part; to see it work in simulation, pair it with the HEX file or the controller model as the tutorial shows.

What is inside the ZIP file

ESP32ModuleTEP.LIB – Proteus library, 25.2 KB
ESP32ModuleTEP.IDX – Library index, 44 B
ESP32 Simulation.DSN – Proteus simulation, 37.6 KB

The archive unpacks to 62.9 KB; there is no README inside, so the steps below stand in for it.

How to download

Use the download panel at the top of this page: after the counter (30 seconds for guests, 10 for members) the black button unlocks and esp32-library-for-proteus.zip comes straight from our content network. If the browser opens it instead of saving, use Save as; extract the whole archive before using anything inside it.

How to install

Step 1: Extract esp32-library-for-proteus.zip with Windows (Extract All), 7-Zip or WinRAR, keeping its folders.
Step 2: Close Proteus and copy ESP32ModuleTEP.LIB and ESP32ModuleTEP.IDX into its LIBRARY folder (Proteus 8: C:\Program Files (x86)\Labcenter Electronics\Proteus 8 Professional\LIBRARY).
Step 3: Start Proteus, press P and search for "ESP32ModuleTEP"; place and wire it as in the tutorial.
Step 4: Open ESP32 Simulation.DSN in Proteus and press Play.

Simulation and results

The included Proteus project (ESP32 Simulation.DSN) is the quickest way to see ESP32 working: open it, press Play and compare with the screenshots in the tutorial. If nothing runs, make sure every library file was copied before Proteus started and that Program File points at the HEX on your disk; the FAQs tab covers the usual causes.

Read the detailed guide

This page is for the files. The tutorial above explains the circuit and the code step by step and shows the working results and the simulation; read it before you build. Questions about the download or the installation go in the comments below; more Proteus downloads are listed further down this page.

The package is free for personal, educational and research projects; credit The Engineering Projects and link to this page when you share it rather than re-uploading the file.

Read ESP32 Library for Proteus

File Structure

esp32-library-for-proteus.zip3 files · 2 folders · 62.9 KB unpacked

ESP32 Library for Proteus/3 files · 62.9 KB

Proteus Library Files/2 files · 25.2 KB

IDX ESP32ModuleTEP.IDXLibrary index 44 B

LIB ESP32ModuleTEP.LIBProteus library 25.2 KB

DSN ESP32 Simulation.DSNProteus simulation 37.6 KB

Gallery6 images from the tutorialOpen the tutorial

The circuit, the board and the results as they appear in ESP32 Library for Proteus. Open an image for its full size.

README

README no readme

This package has no README file. The Install tab explains where each file goes, and the tutorial ESP32 Library for Proteus walks through the whole project.

Development1 release

31 Jul 2023
ESP32 Library for Proteusthis page

The only release of this package so far. When a newer version is published, it appears above with its own download page.

Installation5 steps

From the download to a working project, in order. The steps follow what the package contains.

You will need

Proteus Design SuiteProteus 8 or newer (Labcenter), on Windows
Any archive toolWindows, macOS and Linux extract ZIP files on their own

Steps

1
Extract the archive
Right-click esp32-library-for-proteus.zip and choose Extract All (or open it with 7-Zip or WinRAR) into a folder you can find again. Keep its folder structure (ESP32 Library for Proteus) as it is.
2
Copy the library files into Proteus
Move ESP32ModuleTEP.LIB and ESP32ModuleTEP.IDX into the LIBRARY folder of your Proteus installation: C:\Program Files (x86)\Labcenter Electronics\Proteus 8 Professional\LIBRARY for Proteus 8, or the matching Proteus 7 folder. Older versions keep it under ProgramData\Labcenter Electronics. If Proteus is open, close it first.
3
Restart Proteus and place the component
Start Proteus, open a schematic, press P (Pick Devices) and search for the component by the name used in the tutorial. It appears with its pins ready to wire.
4
Open the example simulation
Open ESP32 Simulation.DSN in Proteus to see the wiring exactly as in the tutorial. Check the controller's Program File path, then press Play.
5
Follow the tutorial
ESP32 Library for Proteus explains every connection and setting in order; keep it open beside the files while you build.

How to add a library in Proteus 8

FAQs9 questionsContact TEP

How do I download ESP32 Library for Proteus?

Wait for the 30-second guest countdown on this page, then press the download button; the file comes straight from our storage. Members who are logged in skip the wait. If the browser opens the file instead of saving it, use its Save as option. The download link is made for you when the countdown ends and works for 15 minutes; a saved or shared link stops working, so share this page instead.

What is inside the archive?

ESP32 Library for Proteus comes as a ZIP archive of 3 files (11.6 KB, 62.9 KB unpacked) holding Proteus library files and a Proteus simulation. Open the File Structure tab for the full list of 3 files.

What should I do if the download does not start?

Check the browser's download list first; an ad blocker or a company firewall can also hold it back, so try another browser or network. If the file arrives incomplete, download it again. For an installation problem, read the Install tab or tell us in the comments with your software version and the exact error message.

Is this file free?

Yes. Every file in the TEP Download Center is free for learning, personal and student projects. If you share it, link back to this page or the tutorial so others find the latest version.

How do I check that the file arrived complete?

Compare its SHA-256 with the one on this page, e4f86856bf11cd1066fbf9b3f2035dd930b07f0cf4f25f8d13af8bda912cc8ff. In PowerShell run Get-FileHash "esp32-library-for-proteus.zip"; on macOS or Linux run shasum -a 256 "esp32-library-for-proteus.zip". The same value means the file is exactly the one in our storage; a different one means the download broke off, so download it again.

Do I need WinRAR to open the ZIP file?

No. Windows, macOS and Linux open ZIP archives on their own (Extract All, or double-click). WinRAR and 7-Zip work too. Extract the whole archive before using the files.

Where do I put the LIB and IDX files?

Both files go into the LIBRARY folder of your Proteus installation (Proteus 8: C:\Program Files (x86)\Labcenter Electronics\Proteus 8 Professional\LIBRARY; Proteus 7 has the same folder under its own name). Restart Proteus afterwards and search for the component with P.

Which Proteus version does the library need?

The tutorial names the Proteus version the library was made and tested with. Most TEP libraries work in Proteus 7 and Proteus 8; if the component does not appear after a restart, check that both the LIB and the IDX file were copied and that Proteus was fully closed while copying.

Why does the component show but not simulate?

A library without a model file (DLL) gives you the symbol and the pins for drawing and PCB design; the simulation needs the matching model or a HEX file on the controller, exactly as the tutorial describes.
